ASTM E136

$44.00

Standard Test Method for Assessing Combustibility of Materials Using a Vertical Tube Furnace at 750 °C

Published by ASTM International, 10/01/2022

PDF

All of our standards are available in PDF (Portable Document Format), an electronic, downloadable format.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.

ASTM E136, 2022 Edition – Standard Test Method for Assessing Combustibility of Materials Using a Vertical Tube Furnace at 750 °C

This fire-test-response test method covers the determination under specified laboratory conditions of the combustibility of building materials. Materials passing this test are typically classified as noncombustible materials.

Limitations of this fire-test response test method are shown below.

This test method does not apply to laminated or coated materials.

This test method is not suitable or satisfactory for materials that soften, flow, melt, intumesce or otherwise separate from the measuring thermocouple.

This test method does not provide a measure of an intrinsic property.

This test method does not provide a quantitative measure of heat generation or combustibility; it simply serves as a test method with selected (end point) measures of combustibility.

The test method does not measure the self-heating tendencies of materials.

In this test method materials are not being tested in the nature and form used in building applications. The test specimen consists of a small, specified volume that is either (1) cut from a thick sheet; (2) assembled from multiple thicknesses of thin sheets; or (3) placed in a container if composed of granular powder or loose-fiber materials.

Results from this test method apply to the specific test apparatus and test conditions and are likely to vary when changes are made to one or more of the following: (1) the size, shape, and arrangement of the specimen; (2) the distribution of organic content; (3) the exposure temperature; (4) the air supply; (5) the location of thermocouples.

This test method includes two options, both of which use a furnace to expose test specimens of building materials to a temperature of 750 °C (1382 °F).

The furnace for the apparatus for Option A consists of a ceramic tube containing an electric heating coil, and two concentric vertical refractory tubes.

The furnace for the apparatus for Option B (Test Method E2652) consists of an enclosed refractory tube surrounded by a heating coil with a cone-shaped airflow stabilizer.

This test method references notes and footnotes that provide explanatory information. These notes and footnotes, excluding those in tables and figures, shall not be considered as requirements of this test method.

The values stated in SI units are to be regarded as standard. The values given in parentheses are for information only.

This standard is used to measure and describe the response of materials, products, or assemblies to heat and flame under controlled conditions, but does not by itself incorporate all factors required for fire-hazard or fire-risk assessment of the materials, products, or assemblies under actual fire conditions.

Fire testing is inherently hazardous. Adequate safeguards for personnel and property shall be employed in conducting these tests.

This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use.

This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.

General Product Information:

Revision 2022 Edition
Document Type PDF
Document Language English
Pages 13
Publisher ASTM International (ASTM)
Status Current

ASTM Volume

04.07: Building Seals And Sealants; Fire Standards; Dimension Stone

Specifications, tests, and practices detail the property requirements for caulking and glazing compounds; structural, emulsion, hot-applied, and solvent-release sealants; lock-strip gaskets; aerosol foam sealants; pipe gaskets; sealing tapes; and other building sealants. Also featured are standards on how to measure sealant properties.

It includes test methods on the combustibility and fire resistance of various materials, including building construction materials, mattresses, and upholstered furniture. Other standards cover fire safety engineering and large-scale fire tests under controlled conditions.

Volume 04.07 also includes standards on dimension stone, including dimension stone anchoring systems and selection of dimension stone for different applications.
