ASME Y14.5

$129.00

Dimensioning and Tolerancing

2018 Edition

Published by ASME International, 02/11/2019

PDF

All of our standards are only available in PDF (Portable Document Format), an electronic, downloadable format.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.

ASME Y14.5, 2018 Edition – Dimensioning and Tolerancing

ASME Y14.5 is the newest standard from ASME which establishes symbols, rules, definitions, requirements, defaults, and recommended practices for stating and interpreting geometric dimensioning, tolerancing, and related requirements for use on engineering drawings, models defined in digital data files, and related documents. For a mathematical explanation of many of the principles in this Standard, see ASME Y14.5.1M. Additional uniform practices for applying dimensions, tolerances, and related requirements in digital data sets are defined in ASME Y14.41. Practices unique to architectural and civil engineering and welding symbology are not included in this Standard.
Sections 1 through 4 establish references definitions, fundamental rules, and practices for general dimensioning.
For tolerancing practices, see Sections 5 through 12. Additional information about tolerancing is in Mandatory Appendix I and Nonmandatory Appendices A through D.

General Product Information:

Document Type PDF
ISBN 9780791872192
Pages 347
Document Language English
Publisher American Society of Mechanical Engineers (ASME)
Status Current
